High Light: | air plasma,air plasma cutter,inverter air plasma |
---|
1. MOSFET inverter and precision constant current feedback control technology, soft switch, 100 kHz of cutting frequency;
2. Wide working voltage range, strong adaptability to electricity power grid, high ability of interference resistance, stable cutting current and steady arc, automatic voltage compensation;
3. 110/220 duel voltage input, automatic input voltage shift, secondary boost for arc strike, ensure no breakdown of the coil;
4. Continuous current regulation, little distortion for work-piece, safety and reliable for operation;
5. Suitable for carbon steel, stainless steel, aluminum, copper, etc.
Model Spec. | CUT-60 |
Power supply voltage | AC 110+15% V / 50~60 Hz |
AC 220+15% V / 50~60 Hz | |
Power supply capacity | 7.5 kVA |
No-load voltage | 240 V |
Current range | 10-80 A |
Power output voltage | 108 V |
Duty cycle | 60% |
ARC initiation | Contact / Non- Contact |
Power factor (η) | 0.93 |
Air pressure | 5 MPa |
Protection | IP 21 S |
Insulation | B |
Cutting thickness | 1-20 mm |
Weight | 12.5 kg |
Dimensions (mm) | 570*322*450 |
